Model: R17-A
Frequency: 902~928MHz
Interface: USB wired
Support cards: ISO 18000-6C
Introduction: R17-A USB is a small desktop reader, compatible with ISO 18000-6C standard. The operating frequency is 902MHz~928MHz. It is a small integrated reader that can be used for short-distance identification or background card issuer management. Easy to carry, suitable for personnel access control, picture file management, and back-end electronic tag reading, writing, authorization, formatting and other operations.
- Parameters
- Pictures
- Downloads
| Working frequency: | National standard (920~925MHz) American Standard (902~928MHz) Other multinational frequency standards (customized) |
| Label Agreement: | ISO18000-6C (EPC GEN2) |
| Frequency hopping method: | Broad spectrum frequency hopping (FHSS) or fixed frequency that can be set by software; |
| Antenna parameters: | 2dBi circular polarization antenna (built-in) |
| Output Power: | 12.5dBm~26dBm (software adjustable) |
| Reading distance: | The maximum reading distance of the tag: 0.5m (related to factors such as transmit power, antenna type, tag type and application environment) Maximum distance to write tags: 0.2m (depending on factors such as transmit power, antenna type, tag type and application environment) |
| Operating mode: | Active mode Passive mode Answer mode (not recommended) |
| Power interface: | DC +5V |
| Operating temperature: | -20℃～55℃ |
| Storage temperature: | -40℃～85℃ |
| Communication Interface: | USB virtual keyboard USB virtual serial port (need to be customized) |
| Size: | 107mm×107mm×24mm |
| Weight: | 150g/250g |
